G156XTT01.1 AUO 15.6inch 1366×768 LCD DISPLAY

G156XTT01.1 AUO 15.6inch 1366×768 LCD DISPLAY

Name: Executive Anvil
Rating: 4.4 (89 reviews)

The AUO G156XTT01.1 is a 15.6-inch WXGA (1366x768) industrial TFT-LCD module with an integrated capacitive touch panel. It features wide-temperature operation and an LVDS interface for robust applications.

Price: ~~$155.00~~ $150.00 / piece

Quantity:		Unit(s) MOQ: 1



Add to wish list

Calculate shipping price

WINNI (HK) ELECTRONIC CO., LIMITED

Invshop168

+8613827441621

winnihk88@winnihk.com

facebook:invshop@163.com

youtube:invshop-com

linked:Linkedin

Require:*

Product Model*	Target price	Qty *

Message

Your contact info:

Additional info:

Name: *

Mr.

Ms.

1. Quote with shipping freight?

Email : *

YES

Phone:

2. Which carrier do you perfert?

Company:

	Fedex		UPS		DHL
	TNT		other

Country:*

All Categories

-81%
OFF

FF300R06KE3 INFINEON IGBT module

$55.00

$100.00

Producrts Details

Inventory Information

Seller Guarantees

Feedback

Reveiw

G156XTT01.1 AUO 15.6inch 1366×768 LCD DISPLAY

G156XTT01.1 Datasheets Download

Name: G156XTT01.1.pdf

Type

LCD DISPLAY

Brand

AUO

Model

G156XTT01.1

Parameter description：

1. Brand:AUO

2. Size:15.6Inches

3. Model:G156XTT01.1

4. Panel type:a-Si TFT-LCD, LCM

5. Resolution: 1366(RGB)×768, WXGA 100PPI

6. AA zone size:344.232(W)×193.536(H) mm

7. Overall dimensions:363.8(W)×215.9(H)×12.5(D) mm

8. Brightness:350 cd/m² (Typ.)

9. Viewing angle:85/85/80/80 (Typ.)(CR≥10)

10. Contrast ratio:500 : 1 (Typ.) (TM)

11. Display color:

12. Optical mode: TN, Normally White, Transmissive

13. Response speed:

14. Signal interface: LVDS (1 ch, 8-bit) , 30 pins Connector

15. Light source type:WLED , 50K hours , With LED Driver

16. Touch: PCAP, Air Bonding, USB

17. Working environment:Storage Temp.: Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C

Parameter description：

1. Brand:AUO

2. Size:15.6Inches

3. Model:G156XTT01.1

4. Panel type:a-Si TFT-LCD, LCM

5. Resolution: 1366(RGB)×768, WXGA 100PPI

6. AA zone size:344.232(W)×193.536(H) mm

7. Overall dimensions:363.8(W)×215.9(H)×12.5(D) mm

8. Brightness:350 cd/m² (Typ.)

9. Viewing angle:85/85/80/80 (Typ.)(CR≥10)

10. Contrast ratio:500 : 1 (Typ.) (TM)

11. Display color:

12. Optical mode: TN, Normally White, Transmissive

13. Response speed:

14. Signal interface: LVDS (1 ch, 8-bit) , 30 pins Connector

15. Light source type:WLED , 50K hours , With LED Driver

16. Touch: PCAP, Air Bonding, USB

17. Working environment:Storage Temp.: Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C

Quality: test ok before ship it
RMA Policy: RMA 3 month
Quantity: 20
Sample: Paid Sample
Stock Location: China
Delivery: WorldWide
Lead Time: 3-5 Days
Price Term: T/T, Paypal Western Union, MoneyGram, PayPal, Escrow etc
Remark: NEW
Weight: 2.500Kg
