used Schneider Inverter ATV31H055M2A 0.55KW 220V ATV31

used Schneider Inverter ATV31H055M2A 0.55KW 220V ATV31

*Fast delivery
*Original & Brand New
*Best price
*Good quality
*Excellent service

Price: ~~$0.00~~ $0.00 / piece

Quantity:		Unit(s) MOQ: 1



Add to wish list

Calculate shipping price

WINNI (HK) ELECTRONIC CO., LIMITED

Invshop168

+8613827441621

winnihk88@winnihk.com

facebook:invshop@163.com

youtube:invshop-com

linked:WINNI (HK) ELECTRONIC CO., LIMITED

Require:*

Product Model*	Target price	Qty *

Message

Your contact info:

Additional info:

Name: *

1. Quote with shipping freight?

Email : *

Phone:

2. Which carrier do you perfert?

Company:

	Fedex		UPS		DHL
	TNT		other

Country:*

All Categories

-81%
OFF

$55.00

$100.00

Products Details

Inventory Information

Seller Guarantees

Feedback

Reveiw

Frequency inverter

Brand

SCHNEIDER

Model

ATV31H055M2A

Product Name		used Schneider Inverter ATV31H055M2A 0.55KW 220V ATV31
Model		ATV31H055M2A
Quality		Each itE3X-NM11 em must be tested OK before shipping
MOQ		1 pcs
Discount		More quantity, larger discount
Payment		T/T, Western Union, MoneyGram, PayPal, Escrow etc
Package		Anti-static bag, Bubble bag, Carton box
Delivery Time		In 1-3 working days after payment confirmed
Shipping		DHL, EMS, Fedex, UPS, TNT, HK Post Air Mail etc
Warranty		90 days warranty

1. Product Identification

Manufacturer: Schneider Electric
Product Line: Altivar 31
Type: Variable Frequency Drive (VFD) / Adjustable Speed Drive (ASD)
Full Model: ATV31H055M2A
Marketing Name: Altivar 31

2. Technical Specifications

Power Specifications

Parameter	Specification
Rated Power	0.55 kW (0.75 HP)
Rated Output Current	1.7 A at 200-240V (3-phase)
Maximum Output Current	2.2 A (for 60s)
Input Voltage	200-240V AC, 3-phase (-15%/+10% tolerance)
Input Frequency	50/60 Hz ± 5%
Output Voltage	0 to input voltage, 3-phase
Output Frequency	0.5 to 400 Hz (programmable)

Performance Characteristics

Parameter	Specification
Control Method	Flux Vector Control (sensorless)
Speed Control Range	1:40 without encoder (sensorless)
Speed Regulation	±2% of rated speed (sensorless)
Starting Torque	150% at 3 Hz (sensorless)
Overload Capacity	110% continuous, 150% for 60s
Switching Frequency	4 kHz (default), adjustable 2-16 kHz
Efficiency	>97% typical

Control & I/O Specifications

Parameter	Specification
Control Inputs	• 3 digital inputs (programmable) • 1 analog input (0-10V/0-20mA selectable) • 1 logic input (+24V)
Control Outputs	• 1 relay output (changeover contact) • 1 analog output (0-10V/0-20mA programmable) • 1 logic output (+24V, 50mA max)
Communication	• Built-in Modbus RS-485 (optional card for other protocols) • Optional communication cards: CANopen, DeviceNet, Profibus DP
Keypad/Display	Integral keypad with 4-digit LED display

Protection Features

Category	Protection Functions
Motor Protection	• Electronic thermal overload • Short circuit protection • Ground fault protection • Motor stall protection • Phase loss protection
Drive Protection	• Overvoltage/Undervoltage • Overcurrent • Heatsink overtemperature • IGBT protection • Input phase loss
System Protection	• Fault contact output • Auto restart • Ride-through capability

Environmental Specifications

Parameter	Specification
Operating Temperature	-10°C to +50°C (14°F to 122°F) without derating -10°C to +40°C (14°F to 104°F) with full performance
Storage Temperature	-25°C to +70°C (-13°F to 158°F)
Relative Humidity	5% to 95% non-condensing
Altitude	0-1000m without derating 1000-4000m with derating (2.5% per 300m above 1000m)
Pollution Degree	2 according to IEC 60721
Overvoltage Category	III (IEC 61800-5-1)
Vibration	0.7g, 10-150Hz (IEC 60721-3-3)
Shock	5g, 11ms (IEC 60721-3-3)

Physical Specifications

Parameter	Specification
Enclosure Rating	IP20 (open chassis)
Dimensions (W×H×D)	Approximately 73 × 155 × 140 mm (2.9 × 6.1 × 5.5 in)
Weight	Approximately 1.1 kg (2.4 lbs)
Mounting	Wall mount, panel mount, or DIN rail (with adapter)
Cooling	Convection cooled (no fan)

3. Code Breakdown: ATV31H055M2A

ATV31: Altivar 31 series
H: 200-240V AC input voltage range
055: 0.55 kW power rating
M2: 3-phase input, 3-phase output
A: Version/option code (typically indicates standard features)

4. Standards & Certifications

Standard	Description
UL	UL 508C (Industrial Control Equipment)
cUL	CSA C22.2 No. 14
CE	EMC Directive 2014/30/EU, LVD Directive 2014/35/EU
IEC	IEC 61800-2, IEC 61800-3 (EMC)
EN	EN 61800-2, EN 61800-3
RoHS	Compliant with Directive 2011/65/EU

5. Application Information

Typical Applications

Pumps and pumping systems
Fans and blowers
Conveyors and material handling
Mixers and agitators
Compressors
Machine tools

Motor Compatibility

Standard asynchronous (induction) motors
2-pole, 4-pole, 6-pole motors
Motor voltage: 200-240V Δ / 380-480V Y
Suitable for constant and variable torque applications

Installation Requirements

Requirement	Specification
Input Protection	Circuit breaker or fuse required (see manual for sizing)
Input Disconnect	Required per NEC/installation standards
EMC Filter	Built-in Class A filter (optional external filter for Class B)
Braking	Dynamic braking (DB) resistor optional
Cable Length	Max 50m (shielded), 100m (unshielded) without output filter

6. Programming & Configuration

Programming Methods

Integrated Keypad: 4-digit LED, navigation buttons
Software: SoMove (PC configuration software)
Communication: Modbus RS-485

Key Parameters

Parameter Group	Examples
Simplified Setup	Motor data, acceleration/deceleration times
Input/Output	Digital input functions, analog scaling
Application Functions	PID, presets, skip frequencies
Motor Control	Current limits, slip compensation
Fault Management	Auto-restart, fault responses

7. Accessories & Options

Communication Cards:

VW3 A3 101 (CANopen)
VW3 A3 102 (DeviceNet)
VW3 A3 103 (Profibus DP)

I/O Extension Cards: Additional digital/analog I/O
Braking Resistors: Various power ratings
EMC Filters: External filters for Class B compliance
DIN Rail Adapter: VW3 A5 301
Remote Keypad: Separate mounting option
