Name: HSD190MEN3-A00.pdforiginal HSD190MEN3-A00 19"HannStar LCD panel 1280*1024
Product Overview
Actual testing and customer installation verify that HSD190MEN3-A00 supports long‑hour continuous operation with uniform brightness and stable color performance. Its standard mechanical dimensions and mounting holes simplify replacement and upgrade for legacy equipment. Real applications include industrial HMI panels, medical monitoring displays, factory automation terminals and office equipment, where HSD190MEN3-A00 maintains reliable performance under continuous operation.
HSD190MEN3-A00 adopts a transmissive TFT structure with 16.7M high color depth and 72% NTSC color gamut, providing realistic color restoration. Wide viewing angles of 85/85/80/80° (L/R/U/D, CR≥10) ensure clear viewing from multiple directions. It uses a 30-pin LVDS signal interface and 4‑lamp CCFL backlight, supporting long‑term stable operation. Operating temperature ranges from 0°C to 50°C, storage temperature from -20°C to 60°C, meeting the environmental requirements of industrial and medical scenarios. Professional parameters make HSD190MEN3-A00 highly compatible with mainstream driver boards.
HSD190MEN3-A00 Product Specifications Table
| Model: | HSD190MEN3-A00 | Panel Type: | a-Si TFT-LCD, LCM |
| Size: | 19" | Power Supply: | 5.0V (Typ.) |
| Pixel Number: | 1280(RGB)×1024, SXGA, 5:4 | Frame Rate: | 75Hz |
| Active Area: | 376.32(W)×301.056(H) mm | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Luminance: | 300 cd/m² (Typ.) | Operating Mode: | TN, Normally White, Transmissive |
| Viewing Angle: | 85/85/80/80 (Typ.)(CR≥10) | Response Time: | 1.2/3.8 (Typ.)(Tr/Td) mm |
| Support Color: | 16.7M, 73% NTSC | Light Source: | 4 pcs CCFL, 40K hrs, Without Driver |
| Interface: | LVDS (2 ch, 8-bit), 30 pins Connector | Operating Temp: | 0 ~ 50 °C |
Image Display
FAQ
Q1: Is HSD190MEN3-A00 compatible with my industrial HMI?
A: Yes. HSD190MEN3-A00 uses standard 1280×1024 SXGA timing and 30-pin LVDS interface, with universal mechanical dimensions for most 19-inch industrial panels.
Q2: Does HSD190MEN3-A00 include a backlight driver?
A: No. It is equipped with 4 CCFL backlight lamps but no built-in inverter/driver; a matching backlight driver is required.
Q3: Can HSD190MEN3-A00 run 24/7 continuously?
A: Yes. It is designed for long‑term stable operation, suitable for industrial and medical equipment that needs non‑stop working.
Q4: What is the backlight service life?
A: Typical backlight service life is over 30,000 hours, supporting long‑term use of equipment.
Q5: How to get the official datasheet?
A: Contact us to get the complete HannStar official datasheet for HSD190MEN3-A00, including mechanical drawings, electrical parameters and pin definitions.
Product Applications
HSD190MEN3-A00 is widely used in:
