lq133t1jw02 13,3 zoll lcd - panels sharp 2560 * 1440
lq133t1jw02 13,3 zoll lcd - panels sharp 2560 * 1440
lq133t1jw02 13,3 zoll lcd - panels sharp 2560 * 1440
lq133t1jw02 13,3 zoll lcd - panels sharp 2560 * 1440

lq133t1jw02 13,3 zoll lcd - panels sharp 2560 * 1440

The Sharp LQ133T1JW02 is a 13.3-inch TFT-LCD module with QHD (2560×1440) resolution. It features 350 cd/m² brightness, 1000:1 contrast ratio, WLED backlight, and eDP interface.
Der Preis: £54.61 £50.71 / Mitglied
数量: Unit(s)     MOQ: 1

Anfrage

In Favoriten
Zahlung
Zahlung
Zahlung
Zahlung
Zahlung
Berechnung der fracht
WINNI (HK) ELECTRONIC CO., LIMITED
+0086 13827441621
+86-13827441621
RM 3, 27 /F HO COMM CTR NO 2 -16 FA YUEN ST MONG KOK KL
Erforderlich:*
Produktmodell* Zielpreis Qty *
Nachricht
Ihre Kontaktdaten: Weitere Informationen:
Name: *
Herr. Frau.
1. Angebot mit Versand Fracht?
Email : *
JA NEIN
Telefon: 2. Welchen Carrier perfert ihr??
Unternehmen:
Fedex UPS DHL
TNT andere
Land:*
Produkte Klassifizierung
LQ133T1JW02 Zusammenfassung
The Sharp LQ133T1JW02 is a 13.3-inch a-Si TFT-LCD display module designed primarily for laptops, such as the Acer S7-392. It delivers high Quad-HD resolution (2560(RGB)×1440) with a pixel density of 221 PPI. The panel utilizes VA technology with a "Normally Black" transmissive mode. Key specifications include a typical brightness of 350 cd/m², a contrast ratio of 1000:1, and wide viewing angles of 80/80/80/80. It covers 100% sRGB color gamut and displays 16.7 million colors. The module employs a WLED side-light backlight system (with a typical lifespan of 10,000 hours and an integrated LED driver) and communicates via an eDP interface (specified as eDP 1.3 with 4 lanes and 40-pin connector). It operates within a temperature range of 0°C to 50°C.
